MST-030-CA

SOFTSTART 30A 208-575V 10, 20, 25HP OPEN
Ship Weight 9.000 LB
UPC 781568672945
Product has been discontinued

Specs

AMPS IEC 30.00 a
AMPS UL Class 10 28.00 a
Enclosure OPEN UL TYPE 0 IP20
Frame A
Rated Operational Voltage 575 V
Maximum Altitude 3300 FT
Ambient Temperature 40 °C
AMPS UL Class 30 15.00 a
Depth 7.7000 IN
Dual Overload Protection YES
Electronic Overload Protection YES
Height 10.2400 IN
High Current Protection YES
Locked Rotor Protection YES
Phase Imbalance Protection YES
Phase Reversal Protection YES
Programmable Inputs 2
PTC Connection Protection YES
Rated Insulation 690 V
Normal Duty, HP, 208V 7.50 HP
Normal Duty, HP, 230V 10.00 HP
Normal Duty, HP, 460V 20.00 HP
Normal Duty, HP, 575V 25.00 HP
Underload Protection YES
Width 6.3000 IN
